1.Suitable for the adhesive materials. Fully automatic unattended.
2. Conveying the materials stably, forcefully and evenly by vibration and rotation. No material alarm(optional).
3. Amplitude adjustable to control the flow.
4.Electromagnet type plus mechanical vibration thrust, simple structure, simple and convenient installation and maintenance.
5.Simple structureeasy to install and maintain,low maintainance cost, long service life.
6. Low noise, low power consumption, small volume, environmental protection machine.
1. Body material: 304 stainless steel, carbon steel.
2.Material contract material is 304#.
3. Rotate plate: Dia. 480mm,Height 210mm(standard) right or left rotation.
4. Accept customized according to customer's drawings.
Dry Fruits
Candy
parts
plastic Granules
screw
| Machine name | Disc spiral feeder |
| Model | XY-YP50 |
| machine frame | #304 Stainless steel |
| Hopper capacity | 13L |
| Feed capacity | 3 m³ /H |
| Vibration groove length | 60MM |
| Vibrating noisy | < 40dB |
| Voltage | Single-phase, two-phase or three-phase 180-220V, three-phase 350V-450V,50-90Hz |
| Power supply | 420W |
| Packing size | L650mm*W650mm*H500mm |
| Weight | 150KG |
